1500/2000/2500/3000kgLOAD CAPACITY |
540/685mmOutside Fork Spread |
1150/1220Length of the Fork |
Specifications | ||
Model | CBY-BF | |
Load Capacity | kg | 1500/2000/2500/3000 |
Lowest Fork Height | mm | 85 |
Maximum Fork Height (H2) | mm | 200 |
(Outside Fork Spread(B) | mm | 540/685 |
Length of the Fork(L2) | mm | 1150/1220 |
Width of the Fork(B1) | mm | 160x50 |
Head Length(L1) | mm | 395 |
Dia.Of the Front Wheel | mm | Single Φ80x93/double Φ80x70 |
Dia.Of the Steering Wheel | mm | 180x50 |
Material Of the Wheel | Nylon/Polyurethane/Rubber | |
Height of handle from the ground(H) | mm | 1230 |
Net Weight | kg |
540Nylon-72kg / 685Nylon-80kg 540PU-80kg/685PU-88kg |
Q'ty in one 20'Container | 540 180 pcs / 685 144 pcs |
Ningbo Yinzhou Walsun Machinery Factory, as famous China 2.5 Ton/3 Ton Hydraulic Hand Pallet Truck- Model BF Series Suppliers and China OEM 2.5 Ton/3 Ton Hydraulic Hand Pallet Truck- Model BF Series factory, has sufficient production capacity and high control over raw material prices, quality and stable supply, laying the foundation for continuous production; the company has a reasonable sales and warehousing network and efficient operation mechanism to ensure domestic shipments within one week, and foreign trade orders are based on customer needs can be shipped on time.
The company strictly implements the procedures of screening and reviewing raw material suppliers, incoming material testing, and incoming material comparison; excellent production process design and program control make each batch of 2.5 Ton/3 Ton Hydraulic Hand Pallet Truck- Model BF Series more stable and traceable, and obtain high-efficiency production control; strict In accordance with the supplier's indicators, each batch of 2.5 Ton/3 Ton Hydraulic Hand Pallet Truck- Model BF Series is inspected and monitored for quality.
Our 2.5 Ton/3 Ton Hydraulic Hand Pallet Truck- Model BF Series are widely used in various production companies such as hardware machinery, textiles, food, medicine, logistics, and supermarkets, homes, and shopping malls.
